3 Product description
3 .1 Structure
The scope of delivery encompasses:
l VEGAWAVE 61 point level switch
l Documentation
-
this operating instructions manual
-
Safety Manual "Functional safety (SIL)" (optional)
-
Supplementary instructions manual "Plug connector for level
sensors" (optional)
-
Ex-specific "Safety instructions" (with Ex versions)
-
if necessary, further certificates
The VEGAWAVE 61 consists of the components:
l Housing cover
l Housing with electronics
l Process fitting with tuning fork
1
2
3
Fig. 1: VEGAWAVE 61 - with plastic housing
1 Housing cover
2 Housing with electronics
3 Process fitting
The type label contains the most important data for identification and
use of the instrument:
l Article number
l Serial number
l Technical data
l Article numbers, documentation
l SIL identification (with SIL rating ex works)
With the serial number, you can access the delivery data of the
instrument via www.vega.com, "VEGA T
ools" and "serial number
search". In addition to the type label outside, you can also find the
serial number on the inside of the instrument.
Scope of delivery
Constituent parts
Type label
VEGAWAVE 61 • - Relay (DPDT) 7
3 Product description
