9 Supplement
PLICSRADIO D61 • Wireless indicating unit (single channel)
32626-EN-130228
9.2 Dimensions
Electronics housing
1 2
138 mm (5.43"
)
~ 69 mm
(2.72")
~ 88 mm
(3.47")
ø 77 mm
(3.03")
~ 116 mm (4.57")
~ 87 mm (3.43")
ø 84 mm (3.31")
M20x1,5/
½ NPT
M20x1,5/
½ NPT
M20x1,5/
½ NPT
Fig. 14: Electronics housing, the height of the plastic housing increases by 11 mm (0.43 in) with integrated PLIC-
SCOM and of the Alu housing by 9 mm (0.35 in)
1 Plastic housing
2 Aluminium housing
Mounting elements
5mm (
13
/ 64
")
16mm (
5
/ 8
")
84mm (3 5 / 16
")
70mm (2 3 /
4
")
R32mm
(1
17
/ 64
")
M6
67mm (2
41
/ 64
")
~ 111mm (4
31
/ 8
")
3mm ( 1
/ 8
")
11mm ( 7
/ 16
")
60mm (2 23 /
64
")
1 2 3
Fig. 15: PLICSRADIO D61 mounting elements
1 Mounting plate for wall mounting
2 Clip for carrier rail mounting
3 Strap for tube mounting
