9 Supplement
9 .1 Technical data
General data
Material 316L corresponds to 1.4404 or 1.4435
Materials, wetted parts
-
Process fitting - thread 316Ti
-
Process fitting - Cone 316Ti
-
Electrode 316Ti
-
Insulation ring PTFE
-
Process seal Klingersil C-4400
Materials, non-wetted parts
-
Housing plastic PBT (Polyester)
-
Temperature adapter 316Ti
-
Seal between housing and housing
cover Silicone
-
Ground terminal 316L
Weights
-
with plastic housing 600 g (21 oz)
-
Temperature adapter 150 g (5.3 oz)
Process fittings
-
Thread (DIN 3852-A) G 1 A (PN 25)
-
Cone Cone DN 25 (PN 25)
-
Tuchenhagen
Measurement voltage approx. 1 V
ss
, 5 kHz
Measurement current < 1 mA
Output variable
Output Relay output (DPDT), 1 floating spdt
Turn-on voltage
-
min. 10 mV
-
max. 253 V AC, 253 V DC
Switching current
-
min. 10 µA
-
max. 3 A AC, 1 A DC
Breaking capacity
-
min. 50 mW
-
max. 750 VA AC, 54 W DC
If inductive loads or stronger currents are switched
through, the gold plating on the relay contact
