Length HF connection cable to
external housing 2, 5 oder 10 m (6.562, 16.4, 32.81 ft)
Min. dielectric figure of the medium
-
VEGAFLEX 61, 62, 63, 65 ε
r
> 1.6
-
if sensor length L > cable
length HF connection cable ε
r
> 2
Process conditions
Process pressure depending on the process fitting
Ambient temperature - HF con-
nection cable -40 … +85 °C (-40 … +185 °F)
Ambient, storage and transport temperature on the instrument housing
-
without indicating and adjust-
ment module -40 … +80 °C (-40 … +176 °F)
-
with indicating and adjustment
module -20 … +70 °C (-4 … +158 °F)
Electromechanical data
Cable entry/plug 1)
-
Instrument housing
l
1 x cable gland M20 x 1.5 (cable:
ø
6 … 12 mm), 2 x blind stopper
M 20 x 1.5
or:
l
1 x closing cap ½ NPT, 2 x blind
stopper ½ NPT
or:
l
1 x plug (depending on the version),
2 x blind plugs M20 x 1.5
-
Housing socket
l
1 x N-socket
-
Sensor housing
l
1 x N-socket
Spring-loaded terminals for wire cross-section up to 2.5 mm²
(AWG 14)
Electrical protective measures
Protection
-
Sensor housing IP 66/IP 68 (1 bar)
-
Instrument housing - Instru-
ment socket IP 66/IP 67
1) Depending on the version M12 x 1, according to DIN 43650, Harting, Am-
phenol-Tuchel, 7/8" FF.
