5 C onnect the sensor to the external
housing
5 .1 Preparing the connection
Follow the instructions in the operating instructions manual of
the sensor.
5 .2 Connection procedure
Note:
Only use the corresponding HF connection cable in the correct
length.
Make sure that the markings (serial no.) correspond on the
individual parts (sensor housing, instrument housing and HF
connection cable).
The confectioned HF connection cable has a straigth N-plug
on one end and on the other end an N-angled plug. Both plugs
can be connected to any side.
1 Remove the protective cover on the plug connector of the
sensor housing.
2 Insert the plug (straight plug or angle plug) of the HF
connection cable on the sensor housing and hand-screw
the hexagon nut.
3 Tighten the hexagon nut of the plug with the fork wrench
(SW 19) with max. 3 Nm (2.212 lbf ft).
4 Secure the hexagon nut of the plug with the securing strap.
For this purpose, place the securing strap on one surface
of the hexagon nut and tighten it with an Allen key (size 4).
