4 Mounting
4 .1 General instructions
M
ake sure that all parts of the instrument exposed to the process, in
particular the sensor element, process seal and process fitting, are
suitable for the existing process conditions. These include above all
the process pressure, process temperature as well as the chemical
properties of the medium.
Y ou can find the specifications in chapter "Technical data" or on the
type label.
S elect an installation position you can easily reach for mounting and
connecting as well as later retrofitting of an indicating and adjustment
module. The housing can be rotated by 330° without the use of any
tools. You can also install the indicating and adjustment module in four
different positions (each displaced by 90°).
I n case of difficult installation conditions, the probe can be also
mounted laterally. For this purpose, adapt the rod with rod extensions
or bow-shaped segments.
T he sensor must be readjusted to compensate the resulting running
time changes.
Suitability for the pro-
cess conditions
Mounting position
Rod extensions
