l Medium
l Standpipe inner diameter 2)
l Vessel form
l Damping
l Linearisation curve
l Sensor-TAG
l Displayed value
l Scaling unit (Out-Scale unit)
l Positions after the decimal point (scaled)
l Scaling PA/Out-Scale 4 values
l Unit of measurement
l Language
The following safety-relevant data are not read out or written:
l Sensor address
l PIN
Copy sensor data
Copy sensor data?
Basic adjustment
If the "Reset" is carried out, the sensor resets the values of the
following functions to the reset values (see chart):
3)
Function Reset value
Sensor address 126
Max. adjustment 0 m(d)
Min. adjustment Meas. range end in m(d) 4)
Medium Bulk solid
Vessel form not known
Damping 0 s
Linearisation linear
Channel PV lin. %
Sensor-TAG Sensor
Displayed value PA-Out
Extended settings None
Additional PA value Secondary Value 1 %
Out-Scale-Unit %
PV-Out-Scale 0.00 lin-% = 0.0 %
100.0 lin-% = 100 %
Unit of measurement m(d)
2) With standpipe versions.
3) Sensor-specific basic adjustment.
4) Depending on the sensor type, see chapter "Technical data".
Reset
38 VEGAPULS 67 • Profibus PA
6 Set up with the indicating and adjustment module PLICSCOM
