6 Set up with the indicating and
adjustment module PLICSCOM
6.1 Short description
The indicating and adjustment module is used for measured
value display, adjustment and diagnosis. It can be mounted in
the following housing versions and instruments:
l
All sensors of the plics
®
instrument family, in the single as
well as in the double chamber housing (optionally in the
electronics or connection compartment)
l
External indicating and adjustment unit VEGADIS 61
From a hardware version …- 01 or higher of PLICSCOM as
well as a hardware version …- 01, 03 or higher of the
corresponding sensor, an integrated backlight can be switched
on via the adjustment menu. The hardware version is stated on
the type label of the PLICSCOM or the sensor electronics.
Note:
You can find detailed information on the adjustment in the
operating instructions manual "Indicating and adjustment
module".
6.2 Insert indicating and adjustment module
The indicating and adjustment module can be inserted into the
sensor and removed again at any time. It is not necessary to
interrupt the power supply.
Proceed as follows:
1 Unscrew the housing cover
2 Place the indicating and adjustment module in the desired
position on the electronics (you can choose any one of four
different positions - each displaced by 90°)
3 Press the indicating and adjustment module onto the
electronics and turn it to the right until it snaps in.
4 Screw housing cover with inspection window tightly back
on
Removal is carried out in reverse order.
The indicating and adjustment module is powered by the
sensor, an additional connection is not necessary.
Function/Configuration
Mount/Dismount indicat-
ing and adjustment
module
