3 .2 Principle of operation
VEGAWELL 51 is used for level measurement in vessels and
for gauge measurement in deep wells, e.g. in water/sewage
water applications.
1)
T he actual sensor element is the CERTEC ® measuring cell
with rugged ceramic diaphragm. The hydrostatic pressure
causes a capacitance change in the measuring cell via the
ceramic diaphragm. This change is converted into an
appropriate output signal.
T wo-wire electronics 4 … 20 mA for power supply and
measured value transmission on the same cable.
T he supply voltage range can differ depending on the
instrument version.
D
ata for power supply are specified in chapter "Technical
data".
3 .3 Operation
VEGAWELL 51 with 4 … 20 mA electronics has no adjustment
option.
3 .4 Packaging, transport and storage
Y our instrument was protected by packaging during transport.
I
ts capacity to handle normal loads during transport is assured
by a test according to DIN EN 24180.
T he packaging of standard instruments consists of environ-
ment-friendly, recyclable cardboard. For special versions, PE
foam or PE foil is also used. Dispose of the packaging material
via specialised recycling companies.
T ransport must be carried out under consideration of the notes
on the transport packaging. Nonobservance of these instruc-
tions can cause damage to the device.
T
he delivery must be checked for completeness and possible
transit damage immediately at receipt. Ascertained transit
damage or concealed defects must be appropriately dealt
with.
1) F or use in closed vessels under vacuum, VEGAWELL 51 is available with
absolute pressure measuring ranges.
Application range
Functional principle
Voltage supply
Packaging
Transport
Transport inspection
