10 Annex
10.1 Technical data
General data
Materials, wetted parts
-
Process fitting 316L
-
Antenna encapsulated or hygienically
encapsulated PTFE (TFM 1600), PFA plated, PVDF
-
Process seal with hygienically encapsu-
lated antenna FKM (Viton), EPDM
Materials, non-wetted parts
-
Housing Plastic PBT (polyester), Alu die-casting powder-
coated, 316L
-
Seal between housing and housing
cover NBR (stainless steel housing), silicone (Alu/plastic
housing)
-
Inspection window in housing cover for
PLICSCOM Polycarbonate (UL-746-C listed)
-
Ground terminal 316Ti/316L
Torque of the flange screws (min.) 60 Nm (44.25 lbf ft)
Weight
-
Clamp, bolting, depending on size and
housing material 3.5 … 6.0 kg (7.716 … 13.22 lbs)
-
Flanges, depending on flange size and
housing material 4.2 … 15.4 kg (9.259 … 33.95 lbs)
Output variable
Output signal digital output signal, format according to IEEE-754
Cycle time min. 1 s (dependent on the parameter setting)
Sensor address 126 (default setting)
Current value 10 mA, ±0.5 mA
Damping (63 % of the input variable) 0 … 999 s, adjustable
Fulfilled NAMUR recommendations NE 43
Resolution, digital > 1 mm (0.039 in)
Input variable
Measured variable distance between process fitting and product sur-
face
min. distance from flange 50 mm (1.97 in)
Measuring range depending on process fitting
-
Tri-Clamp 2", 3" up to 10 m (32.81 ft)
-
bolting DN 50, DN 80 up to 10 m (32.81 ft)
