10 Supplement
10.1 Technical data
General data
316L corresponds to 1.4404 or 1.4435
Materials, wetted parts
-
Process fitting 316L, Hastelloy C22, Hastelloy C22 plated
-
Seal process fitting - threaded version Klingersil C-4400
-
Antenna cone PTFE (TFM 1600 PTFE), PP
-
seal, antenna system FKM (Viton), FFKM (Kalrez 2035, 6230 (FDA),
6375)
-
Standpipe 316L, Hastelloy C22
Materials, non-wetted parts
-
Housing Plastic PBT (polyester), Alu die-casting powder-
coated, 316L
-
Seal between housing and housing
cover NBR (stainless steel housing), silicone (Alu/plastic
housing)
-
Inspection window in housing cover for
PLICSCOM Polycarbonate (UL-746-C listed)
-
Ground terminal 316Ti/316L
Weight
-
Process fitting - thread, depending on
thread size and housing material 2 … 2.8 kg (4.409 … 6.173 lbs)
-
Process fitting - flange, depending on
flange size and housing material 4.2 … 15.4 kg (9.259 … 33.95 lbs)
-
Standpipe 1.6 kg/m (1.1 lbs/ft)
Standpipe length < 5 .85 m (19.19 ft)
Output variable
Output
-
Signal digital output signal, Foundation Fieldbus protocol
-
Physical layer according to IEC 61158-2
Channel Numbers
-
Channel 1 Primary value
-
Channel 2 Secondary value 1
-
Channel 3 Secondary value 2
Transmission rate 31.25 Kbit/s
Current value 10 mA, ±0.5 mA
Damping (63 % of the input variable) 0 … 999 s, adjustable
