9 Supplement
VEGACAP 66 • - Relay (DPDT)
30020-EN-130916
9 Supplement
9.1 Technical data
General data
Material 316L corresponds to 1.4404 or 1.4435
Materials, wetted parts
Ʋ Process fitting - thread 316L
Ʋ Process fitting - flange 316L
Ʋ Process seal Klingersil C-4400
Ʋ insulation (fully insulated) PTFE
Ʋ Probe (cable fully PTFE insulated:
ø 8 mm/0.315 in)
316L
Ʋ Gravity weight 316L
Materials, non-wetted parts
Ʋ Plastic housing plastic PBT (Polyester)
Ʋ Aluminium die-casting housing Aluminium die-casting AlSi10Mg, powder-coated - basis:
Polyester
Ʋ Stainless steel housing - precision
casting
316L
Ʋ Stainless steel housing, electropol-
ished
316L
Ʋ Seal between housing and housing
cover
NBR (stainless steel housing, precision casting), silicone
(aluminium/plastic housing; stainless steel housing,
electropolished)
Ʋ Ground terminal 316L
Process fittings
Ʋ Pipe thread, cylindrical (DIN 3852-A) G1 A, G1½ A
Ʋ American pipe thread, conical
(ASME B1.20.1)
1 NPT, 1½ NPT
Ʋ Flanges DIN from DN 50, ANSI from 2"
Weight
Ʋ Instrument weight (depending on
process fitting)
0.8 … 4 kg (0.18 … 8.82 lbs)
Ʋ Gravity weight 900 g (32 oz)
Ʋ Cable weight: ø 8 mm (0.315 in) 200 g/m (2.1 oz/ft)
Sensor length (L) 0.4 … 32 m (1.312 … 105 ft)
Max. tensile load (cable) 10 KN (2248 lbf)
Max. torque (process fitting - thread) 100 Nm (73 lbf ft)
Measuring frequency 430 kHz
Output variable
Output
Relay output (DPDT), 2 floating spdts
Switching voltage
