4.2 Mounting preparations VEGAPULS 61, 62, 63
Oscillator PS-E.60KH is suitable for K band VEGAPULS 61,
62, 63 - 4 … 20 mA/HART. The following versions are
available which differ in the approvals:
l
PS-E.60KHX (X = without approvals)
l
PS-E.60KHA (A = approvals CA, DA, EA according to
VEGA product list)
l
PS-E.60KHD (D = approvals KX, KF according to VEGA
product list)
l
PS-E.60KHE (E = approvals CX, DX, CK, CI, DM, XM, CM,
DI, EX, GI, GX, UX, UF according to VEGA product list)
Oscillator PS-E.60KV is suitable for K band VEGAPULS 61,
62, 63 - 4 … 20 mA/HART four-wire. The following versions
are available which differ in the approvals:
l
PS-E.60KVX (X = without approvals)
l
PS-E.60KVA (A = approvals CA, DA, EA according to
VEGA product list)
l
PS-E.60KVD (D = approvals KX, KF according to VEGA
product list)
l
PS-E.60KVE (E = approvals DX, DK, GX, GI, UX, UF
according to VEGA product list)
Oscillator PS-E.60KP suitable for K band VEGAPULS 61, 62,
63 - Profibus PA. The following versions, which differ in their
approvals, are available:
l
PS-E.60KPX (X = without approvals)
l
PS-E.60KPA (A = approval CA, DA, EA according to
product list)
l
PS-E.60KPD (D = approvals KX, KF according to product
list)
l PS-E.60KPE (E = approval CX, DX, CK, DK, GX, GI, XM,
CM, UX, UF according to product list)
Oscillator PS-E.60KF suitable for K band VEGAPULS 61, 62,
63 - Foundation Fieldbus. The following versions are available
which differ in the approvals:
l
PS-E.60KFX (X = without approvals)
l
PS-E.60KFA (A = approvals CA, DA, EA according to
VEGA product list)
l
PS-E.60KFD (D = approvals KX, KF according to VEGA
product list)
4 … 20 mA/HART
4 … 20 mA/HART four-wire
Profibus PA
Foundation Fieldbus
