VEGABAR 21 9
Product description
Zusätzlicher Temperatureinfluß durch Druckmittler
Process connection Temperature coefficient
[mbar/10 K]
FA Flange DN 25 PN 40 acc. to DIN 2501,
seal surface acc. to DIN 2526 Form D
1,8
FB Flange DN 40 PN 40 acc. to DIN 2501,
seal surface acc. to DIN 2526 Form D 1,0
FC Flange DN 50 PN 40 acc. to DIN 2501,
seal surface acc. to DIN 2526 Form D 2,0
FE Flange DN 50 PN 40 with ext. 100 mm 1,9
FG Flange DN 50 PN 40 with ext. 200 mm 2,1
FH Flange DN 80 PN 40 acc. to DIN 2501,
seal surface acc. to DIN 2526 Form D 0,4
FK Flange DN 80 PN 40 with ext. 100 mm 0,5
FN Flange DN 1" 300 lbs acc. to ANSI B 16.5,
seal surface RF 1,8
FO Flange DN 2" 600 lbs acc. to ANSI B 16.5,
seal surface RF 2,0
- by cooling elements,
dependent on diaphragm-ø 0,1 … 1,5 mbar/10 K
- by 1 m capillary line
dependent on diaphragm-ø 0,1 … 15 mbar/10 K
