VEGABAR 21 5
Product description
1.3 Technical data
Mechanical data
Materials, wetted parts
Process connection stainless steel 1.4571
Diaphragm stainless steel 1.4571, Hastelloy C276 or B2,
Monel 400, Tantalum, PTFE-foil on 1.4571
Extension stainless steel 1.4571
Materials, non-wetted parts
Housing high resistance plastic PBT (Polyester)
Earth terminal stainless steel 1.4305
Window of the indicating module Lexan
Weight
VEGABAR approx. 0,8 … 8 kg
(dependent on the isolating system)
Adjustment and indicating elements
Adjustment of the basic functions 2 keys, 1 rotating switch
Menu-guided adjustment with
additional function
- adjustment elements
4 keys
- indicating elements DOT-Matrix display, 3 lines with 7 figures each
Indicating module LC-display with
- bargraph (20 segments)
- digital value (4-digit)
- tendency indicators for raising or falling
values
Electrical data
Connection
Cable entry M20 x 1,5 (for cable-ø 5 … 9 mm)
Screw terminals for cross-section area of conductor up to
2,5 mm 2
Protective measures
Protection 1) IP 65
Protection class III
Overvoltage category III
1) For maintaining the housing protection, the use of the suitable seal for the cable in the Pg is necessary. If
the used seal does not fit with the cable, it should be replaced by a suitable one.
