Connection cable between IP 68 instrument and external housing:
-
Configuration
four wires, one suspension cable, one breather
capillary, screen braiding, metal foil, mantle
-
Wire cross-section
0.5 mm² (AWG 20)
-
Wire resistance
< 0.036 Ω/m (0.011 Ω/ft)
-
Standard length
5 m (16.40 ft)
-
Max. length
180 m (590.5 ft)
-
Min. bending radius at 25 °C/77 °F
25 mm (0.985 in)
-
Diameter approx.
8 mm (0.315 in)
-
Colour - standard PE
Black
-
Colour - standard PUR
Blue
-
Colour - Ex-version
Blue
Indicating and adjustment module
Voltage supply and data transmission
through the sensor
Indication
LC display in dot matrix
Adjustment elements
4 keys
Protection class
-
unassembled
IP
20
-
mounted into the sensor without cover
IP
40
Materials
-
Housing
ABS
-
Inspection window
Polyester foil
Power supply
Operating voltage
-
Non-Ex instrument
9 … 32 V DC
-
EEx-ia instrument
9 … 24 V DC
-
EEx-id instrument
9 … 32 V DC
Operating voltage with lighted indicating and adjustment module
-
Non-Ex instrument
12 … 32 V DC
-
EEx-ia instrument
12 … 24 V DC
-
EEx-id instrument
12 … 32 V DC
Power supply by/max. number of sensors
-
H
1 power supply
max. 32 (max. 10 with Ex)
VEGABAR
64 • Foundation Fieldbus
