VEGA VEGABAR 64 Foundation Fieldbus - Manual (Page 55)

Accuracy
-
in the range of 0 … +100 °C
(+32 … +212 °F) ±3 K
-
in the range of -50 … 0 °C (-58 … +32 °F)
and +100 … +150 °C (+212 … +302 °F) typ. ±4 K
Input variable
Adjustment
Adjustment range of the min./max. adjustment relating to the nominal measuring range:
-
percentage value -10 … 110 %
-
pressure value -20 … 120 %
Adjustment range of the zero/span adjustment relating to the nominal measuring range:
-
zero -20 … +95 %
-
span -120 … +120 % 10)
-
Difference between zero and span max. 120 % of the nominal range
Recommended max. turn down 10 : 1 (no limitation)
Nominal measuring ranges and overload capability in bar/kPa
Nominal range Overload, max. pressure Overload, min. pressure
Gauge pressure
0 … 0.1 bar/0 … 10 kPa 15 bar/1500 kPa -0.2 bar/-20 kPa
0 … 0.2 bar/0 … 20 kPa 20 bar/2000 kPa -0.4 bar/-40 kPa
0 … 0.4 bar/0 … 40 kPa 30 bar/3000 kPa -0.8 bar/-80 kPa
0 … 1 bar/0 … 100 kPa 35 bar/3500 kPa -1 bar/-100 kPa
0 … 2.5 bar/0 … 250 kPa 50 bar/5000 kPa -1 bar/-100 kPa
0 … 5 bar/0 … 500 kPa 65 bar/6500 kPa -1 bar/-100 kPa
0 … 10 bar/0 … 1000 kPa 90 bar/9000 kPa -1 bar/-100 kPa
0 … 25 bar/0 … 2500 kPa 130 bar/13000 kPa -1 bar/-100 kPa
0 … 60 bar/0 … 6000 kPa 200 bar/20000 kPa -1 bar/-100 kPa
-1 … 0 bar/-100 … 0 kPa 35 bar/3500 kPa -1 bar/-100 kPa
-1 … 1.5 bar/-100 … 150 kPa 50 bar/5000 kPa -1 bar/-100 kPa
-1 … 5 bar/-100 … 500 kPa 65 bar/6500 kPa -1 bar/-100 kPa
-1 … 10 bar/-100 … 1000 kPa 90 bar/9000 kPa -1 bar/-100 kPa
-1 … 25 bar/-100 … 2500 kPa 130 bar/13000 kPa -1 bar/-100 kPa
-1 … 60 bar/-100 … 6000 kPa 200 bar/20000 kPa -1 bar/-100 kPa
-0.05 … 0.05 bar/-5 … 5 kPa 15 bar/1500 kPa -0.2 bar/-20 kPa
-0.1 … 0.1 bar/-10 … 10 kPa 20 bar/2000 kPa -0.4 bar/-40 kPa
-0.2 … 0.2 bar/-20 … 20 kPa 30 bar/3000 kPa -0.8 bar/-80 kPa
-0.5 … 0.5 bar/-50 … 50 kPa 35 bar/3500 kPa -1 bar/-100 kPa
10) Values less than -1 bar cannot be set.
