FFKM (Kalrez 6375) -10 … +150 °C (+14 … +302 °F)
-
FFKM (Chemraz 535) -30 … +150 °C (-22 … +302 °F)
Vibration resistance mechanical vibrations with 4 g and 5 … 100 Hz 13)
Shock resistance Acceleration 100 g/6 ms 14)
Electromechanical data - version IP 66/IP 67
Cable entry/plug 15)
-
Single chamber housing l
1 x cable gland M20 x 1.5 (cable: ø 5 … 9 mm),
1 x blind stopper M20 x 1.5
or:
l
1 x closing cap ½ NPT, 1 x blind plug ½ NPT
or:
l
1 x plug (depending on the version), 1 x blind
stopper M20 x 1.5
or:
l
2 x blind stopper M20 x 1,5
-
Double chamber housing l
1 x cable gland M20 x 1.5 (cable: ø 5 … 9 mm),
1 x blind stopper M20 x 1.5; plug M12 x 1 for
VEGADIS
61 (optional)
or:
l
1 x closing cap ½ NPT, 1 x blind stopper
½ NPT, plug M12 x 1 for VEGADIS 61
(optional)
or:
l
1 x plug (depending on the version), 1 x blind
stopper M20 x 1.5; plug M12 x 1 for VEGADIS
61 (optional)
or:
l
2 x blind stopper M20 x 1.5; plug M12 x 1 for
VEGADIS
61 (optional)
Spring-loaded terminals for wire cross-sec-
tion < 2.5 mm² (AWG 14)
13) Tested according to the regulations of German Lloyd, GL directive 2.
14) Tested according to EN 60068-2-27.
15) Depending on the version M12 x 1, according to DIN 43650, Harting, 7/
8" FF.
