Pressure transmitters D86/D87 9
Product description
1.5 Technical data
Measuring range Pressure transmitter D86
Nominal measuring range (gauge pr.) Gauge pr. resistance Low pr. resistance
0…0.1 bar / 0…10 kPa 2.5 bar / 250 kPa -0.1 bar / -10 kPa
0…0.2 bar / 0…20 kPa 5 bar / 500 kPa -0.2 bar / -20 kPa
0…0.4 bar / 0…40 kPa 10 bar / 1 000 kPa -0.4 bar / -40 kPa
0…1.0 bar / 0…100 kPa 25 bar / 2 500 kPa -1.0 bar / -100 kPa
0…2.5 bar / 0…250 kPa 25 bar / 2 500 kPa -1.0 bar / -100 kPa
0…5.0 bar / 0…500 kPa 25 bar / 2 500 kPa -1.0 bar / -100 kPa
0…10.0 bar / 0…1 000 kPa 25 bar / 2 500 kPa -1.0 bar / -100 kPa
0…20.0 bar / 0…2 000 kPa 25 bar / 2 500 kPa -1.0 bar / -100 kPa
Measuring range Pressure transmitter D87
Mechanical data
Materials, wetted parts
Process connection stainless steel 1.4571, 1.4435
Diaphragm Duratherm 600
Materials, non-wetted parts
Housing Alu (seawater resistant) PE-powder coated,
stainless steel 1.4571
External connection housing high resistance plastic PBT (Polyester)
Ground terminal stainless steel 1.4305
Window of the display module safety glass
Weights
Basic weight without housing approx. 1.6 kg
External housing approx. 400 g
Adjustment and display elements
Pressure transmitter
- terminal insert
without adjustment elements
- adjustment insert 2 keys, 1 rotary switch
Nominal measuring range (gauge pr.) Gauge pr. resistance Low pr. resistance
0…0.1 bar / 0…10 kPa 15 bar / 1 500 kPa -0.2 bar / -20 kPa
0…0.2 bar / 0…20 kPa 20 bar / 2 000 kPa -0.4 bar / -40 kPa
0…0.4 bar / 0…40 kPa 30 bar / 3 000 kPa -0.8 bar / -80 kPa
0…1.0 bar / 0…100 kPa 35 bar / 3 500 kPa -1.0 bar / -100 kPa
0…2.5 bar / 0…250 kPa 50 bar / 5 000 kPa -1.0 bar / -100 kPa
0…5.0 bar / 0…500 kPa 65 bar / 6 500 kPa -1.0 bar / -100 kPa
0…10.0 bar / 0…1 000 kPa 90 bar / 9 000 kPa -1.0 bar / -100 kPa
0…20.0 bar / 0…2 000 kPa 130 bar / 13 000 kPa -1.0 bar / -100 kPa
