VEGA-ASCII signal output VEGASCAN 850
DCS
DCS
End
S1
Adr
T1
no.
S2
value2
identification
Number of bytes
1
1
1
3
1
7
2
Range (ASCII)
=
0..9
,
001..060
#
DCS value
or fault
%CR
Example
=
2
,
001
#
-000673
%CR
DCS
DCS
End
Identifier
Address
T1
number
T1
number identification
Number of bytes
1
1
1
3
1
3
1
Range (ASCII)
%
0..9
,
001..060
L
001..060
CR
Example
%
2
,
001
L
2
CR
Enquiry of measured values
High resolution
The same enquiry can be also carried out with high resolution. The enquiry directed to
VEGASCAN 850 is the same; in the answer, more characters are used for the presentation of
the measured value.
Answer from VEGASCAN 850
Telegram from processing system to VEGASCAN 850
Identifier: 1 character, "%“
T1: 1 character ",“ (comma)
T2: 1 character "L“
End identification: 1 character Chr (13) = CR = Carriage Return
Total length of the telegram: 11 characters
n (n= stated number) repetitions
Start character: S1 = 1 character "=“
Address: Adr = 1 characters VEGASCAN 850 address
Separator character: S2 = 1 character ",“ (comma)
Start character: S3 = 1 character "#“
Total length of the telegram: 16 characters
6 digit value
"-“ with negative values
" " with positive values
valid measured value
‘FAULT ’
Fault
1 2 3 4 5 6 7
1 2 3 4 5 6 7
