Electromechanical data
S uspension cable
-
C onfiguration four wires, one suspension cable, one
breather capillary, screen braiding, foil, man-
tle
-
W
ire cross-section 0.5 mm²
-
W
ire resistance ≤ 0.036 Ω/ m
-
T
ensile strength ≥ 1200 N (270 pound force)
-
M ax. length 1000 m (3280 ft) 8)
-
M in. bending radius 25 mm (with 25 °C/77 °F)
-
D iameter approx. 8 mm (0.315 in)
-
colour (non-Ex/Ex) - PE black/blue
-
colour (non-Ex/Ex) - PUR, FEP blue/blue
C
able entry housing 1 x cable gland M20 x 1.5 (cable: ø 5 … 9 mm),
1 x blind stopper M20 x 1.5
S crew terminals for cable cross-section
up to
1.5 mm² (AWG 16)
Voltage supply
S
upply voltage 9.6 … 36 V DC
P
ermissible residual ripple
-
< 100 H z
U
ss
< 1 V
-
100 H z … 10 kHz U
ss
< 10 mV
L oad see diagram
8) W ith VEGADIS 12: 200 m (656 ft).
