Page 16
16
Pressure transmitter D90 (Profibus PA)
-
PA
+
PA
Transmitter
E21PA
AM10
12
11
10
2
3
1
OK
0 - 20 bar
Setup
Also, the other adjustment steps (adjust PA
output, adjustment etc.) can be carried out
when the processing unit is connected to a
power supply unit. However, adjustment is
also possible at a later time (when the
processing unit is connected to the bus ca-
ble).
Adjustment can be made more convenient by
temporarily mounting the cover or the display
module on the processing unit laterally or
displaced downwards.
Display module
Processing unit
Tighten screws lightly
