6 VEGASWING 81A and 83A
Product description
Overfill protection according to WHG
Level detection with fault monitoring
Instrument Oscillator VEGATOR Test certificate no.
level switch
VEGASWING SWING E82Z EX 536 EX, Z-65.11-154
81A EX, 83A EX 537 EX
636 EX
VEGASWING SWING E82 C Compact instrument Z-65.11-163
81A and 83A SWING E82 R
(C, R, T) SWING E82 T
Level measuring instruments for use in hazardous areas
Level detection with fault monitoring
Instrument EU-type approval VEGATOR Conformity
certificate level certificate
switch
VEGASWING TÜV 98 ATEX 1320 X 536 EX PTB no. Ex 95.D.2065 X
81A EX, 83A EX 537 EX PTB no. Ex 95.D.2073 X
with 636 EX PTB no. Ex 96.D.2068
oscillator
SWING E82Z EX
Overfill protection
The information and conditions of the sup-
plied general type approvals must be noted
when a VEGASWING is used as part of an
overfill pr otection for vessels storing water -
endangered liquids. The general type ap-
proval should be available at the place of
installation place.
VEGASWING should only be used in liquids
against which the materials of the wetted
parts of VEGASWING are sufficiently chemi-
cally resistant.
VEGATOR 425 EX, 534 EX and 825 EX signal conditioning instruments meet the r equired
connection values and can also be used.
DruckbehV (pressure vessel regula-
tions)
VEGASWING was tested acc. to TRB 801 no.
45 on its suitability for use in pressurized
vessels (DruckbehV).
