30 Pressure transmitter D81 METEC ®
Setup
1.3.3
1.3.4
6 Write protect None
7 Descriptor
8 Message
9 PV Snsr s/n
Final asmbly num 0
Revision #’s
1.4
like menu 1.3.4
1.2.3.2
like display 4.1
like display 4.2
1.2.3
1.2.3.1
Safety
enquiry
acknowl-
edge-ment
Indication of the
sensor measuring
range limits
Indication of the
sensor measuring
range limits
(1.3.4.5) Date adjustment
individual text adjustment
Measured value
Modification of the unit
Info on lower and upper measur-
ing range limit as well as min.
span (i.e. the sensor characteris-
tics values)
1.4.1
1.4.2
Adjustment of the integration time
Adjustment of zero and span
Adjustment of zero and span
linear
Indication of the level in % of the
adjusted span
1.4.3
Menu fields (broken line):
Repetition of previous page
}
1.3.3.1
1.3.3.2
Indication of the sensor serial number (like menu window 1.3.4.3)
Unknown Enumerator
General
individual text adjustment
None
Empty adjustment with
medium
Full adjustment with
medium
(1.3.4.4) Measurement loop designation as under menu window 1.3.1
(1.3.4.3) Indication of the sensor serial number
}
A1 A1 A1 A1 A1
B1 B1 B1 B1 B1
1.2.3.1
HART ® menu schematic (continuation)
Generic: SENSOR
Range values
1 PV LRV 0.000mbar
2 PV URV 95.981mbar
3 PV LSL 0.000mbar
4 USL 100.000mbar
HELP HOME
Generic: SENSOR
Device information
1 Distributor
2 Model
Generic
3 Dev id 11017815
4 Tag D84
5 Date 01/01/97
HELP SAVE HOME
Generic: SENSOR
Detailed setup
1 Sensors
2 Signal condition
3 Output condition
4 Device information
SAVE HOME
Generic: SENSOR
PV LRV
0.000 mbar
0.000
HELP DEL ESC ENTER
Generic: SENSOR
PV URV
100.000 mbar
100.000 mbar
HELP DEL ESC ENTER
Generic: SENSOR
Sensors
1 PV 97.214 mbar
2 PV Snsr unit mbar
3 Sensor information
HELP SAVE HOME
Generic: SENSOR
Signal condition
1 Snsr Damp 1.000 s
2 URV 100.000 mbar
3 AI LRV 0.000 mbar
4 Xfer fnctn Linear
5 AI % rnge 97.101 %
HELP SAVE HOME
Generic: SENSOR
Output condition
1 Analog output
2 HART output
SAVE HOME
Generic: SENSOR
Enter values
1 PV LRV 0.000 mbar
2 URV 100.000 mbar
3 PV USL
4 PV LSL 0.000 mbar
HELP HOME
Generic: SENSOR
Calibration
1 Apply values
2 Enter values
HELP SAVE HOME Generic: SENSOR
Apply new 20 mA input
ABBR. OK
Generic: SENSOR
Apply new 4 mA input
ABORT OK
Generic: SENSOR
Set the:
1 4 mA
2 20 mA
3 Exit
ABORTENTER
