12 Pressure transmitter D81 METEC ®
Protective measures 1)
Protection IP 66, IP 67, IP 68
VEGABOX 01 IP 66 and IP 67
Protection class III
Overvoltage category III
Accuracy (similar to DIN 16 086, DIN V 19 259-1 and IEC 770)
Deviation
Reference conditions (acc. to IEC 770)
- temperature
15°C … 30°C
- moisture 45 % … 75 %
- air pressure 86 kPa … 106 kPa
Determination of characteristics limit point adjustment acc. to DIN 16 086
Characteristics linear
Deviation in characteristics incl. hysteresis and repeatability
- Turn Down 1 : 1 < 0.25 % with accuracy class 0.25
< 0.1 % with accuracy class 0.1
- Turn Down up to 1 : 5 typ. < 0.3 % with accuracy class 0.25
typ. < 0.1 % with accuracy class 0.1
- Turn Down up to 1 : 10 typ. < 0.4 % with accuracy class 0.25
typ. < 0.2 % with accuracy class 0.1
Influence of the ambient temperature
Average temperature coefficient
of the zero signal
2)
- Turn Down 1 : 1 < 0.15 %/10 K with accuracy class 0.25
< 0.05 %/10 K with accuracy class 0.1
- Turn Down up to 1 : 5 typ. < 0.225 %/10 K with accuracy class 0.25
typ. < 0.075 %/10 K with accuracy class 0.1
- Turn Down up to 1 : 10 typ. < 0.3 %/10 K with accuracy class 0.25
typ. < 0.1 %/10 K with accuracy class 0.1
Long-term stability
Long-term stability of the zero signal 3) < 0.1 % per 2 years
Other actuating variables
Calibration position upright, diaphragm points downwards
Influence of the installation position < 5 mbar
Vibration resistance mechanical vibrations with 4 g and
5 … 100 Hz, tested acc. to the regulations of
German Lloyd GL characteristics 2
Product description
1) Maintaining the housing protection IP 66 or IP 67 requires the use of a seal that correctly fits the cable in
the cable entry. If the supplied seal does not fit, a suitable seal must be provided by the customer.
2) In compensated temperature range of 0°C … +80°C, reference temperature 20°C
3) Acc. to IEC 770, point 6.3.2 relating to the nominal range
