2
Getting started
Telephone base and charger installation
Install the telephone base and charger(s) as shown below.
If you subscribe to digital subscriber line (DSL) high-speed Internet service
through your telephone line, you must install a DSL filter between the telephone
line cord and the telephone wall jack. Contact your DSL service provider for more
information about DSL filters.
The telephone base comes ready for tabletop use. If you want to mount your
telephone on a wall, refer to Tabletop to wall mount installation on page 6
for details.
Charger Telephone base
Charger adapter
Electrical outlet
not controlled by
a wall switch
Telephone
line cord
A DSL filter (not
included) is required
if you have DSL high-
speed Internet service.
The DSL filter must
be plugged into the
telephone wall jack.
Telephone wall jack
Telephone base
power adapter
Electrical outlet
not controlled by
a wall switch
Use only the power adapters supplied with this product. To order a
replacement, visit our website at www.vtechphones.com or call
1 (800) 595-9511. In Canada, go to www.vtechcanada.com or dial
1 (800) 267-7377.
The power adapters are intended to be correctly oriented in a vertical or floor
mount position. The prongs are not designed to hold the plug in place if it is
plugged into a ceiling, under-the-table or cabinet outlet.
•
•
CAUTION: If you subscribe to telephone service from a cable company or a VoIP
service provider, plug the telephone line cord into the modem/router/terminal
adapter provided by your cable/VoIP service provider. Contact your cable/VoIP
service provider if you have any difficulties in installation.
