8
MULTI-TONE CHIME
Electronic tones can be generated simply and cheaply using this
device. This kit is primarily intended for use as a replacement for
the traditional mechanical doorbell. Of course, it can also be used
for many other types of application. The number of tones may be
selected up to a maximum of three, each of which is output one
after the other. This can be used to help locate the place being
called. Volume and tone can also be set according to help locate
the place being called. Volume and tone can also be set according
to choice and the existing bell transformer can be used as a supply.
Technical data
• Adjustable tone and volume control
• 1, 2 or 3 tones, selectable
• Loudspeaker output: 0.3W/8ohm
• Supply: 6 to 9 VAC/0.2A or 4.5V battery (3 x 1.5V)
• Idle current less than 10 uA
• Dimensions: 53 x 59 x 25 mm
• Usable housing: WCAH2851, G416, G410
• Usable battery holder: BH331B
We reserve the right to make changes
Construction
IMPORTANT
MOUNT ALL COMPONENTS AGAINST THE P.C.B.
USE A SMALL SOLDERING IRON OF MAX. 40W
USE THIN (1mm) SOLDERING TINDO NOT USE SOLDERING
GREASE!
CARELESS ASSEMBLY WILL UNDOUBTEDLY LEAD TO
PROBLEMS
Mount the components in the order indicated in the separate parts
list. The parts marked with (!) require special attention in the
assembly instructions.
