Velleman К8057 User Manual
K8057, 2 channel rf receiver
K8057
ILLUSTRATED ASSEMBLY MANUAL
H8057IP-1
Total solder points: 91
Difficulty level: beginner 1 2
3
4
5
advanced
For use wit
h K8059/VM
108
2 Channel
RF transmi
tter
2 CHANNEL RF RECEIVER
Specifications
Power supply : 9 to 12V AC or DC / 100mA max.
Relay contacts NO / NC: 3A each.
Selectable timers per output
Open field range of up to 30m possible.
On board antenna or external antenna.
Dimensions : 100 x 82mm.
