4
Welcome to the world of Pc Welcome to the world of Pc Welcome to the world of Pc Welcome to the world of Pc----Lab2000 Lab2000 Lab2000 Lab2000 LT LT LT LT
For the PCSGU250 unit, a complete USB-powered lab-in-a-box!
Feature-packed PCLab2000LT software for two channel oscilloscope, spectrum
analyzer, recorder, function generator and Bode plotter. Integrated signal wave
editor and automated sequence generator, using file or external input.
T TT The hardware is not necessary to evaluate the software in Demo mode .
Welcome Welcome Welcome Welcome
Function generator Function generator Function generator Function generator
• frequency range: sine from 0.005Hz to 1MHz
• square and triangle from 0.005Hz to 500kHz
• extended waveform library
• amplitude range: 100mVpp to 10Vpp @ 1KHz//
600ohm load / output impedance: 50ohm
Oscilloscope
Oscilloscope Oscilloscope Oscilloscope
• bandwidth: two channels DC to 12 MHz ±3dB
• input impedance: 1 Mohm / 30pF
• maximum input voltage: 30V (AC + DC)
• time base: 0.1µs to 500ms per division
• input range: 10mV to 3V/division
• readouts: True RMS, dBV, dBm, p to p, Duty
cycle, Frequency…
• record length: 4K samples / channel
• sampling frequency: 250Hz to 25MHz
• sample history and digital grab function
Bode plotter
Bode plotter Bode plotter Bode plotter
• Automated sync between oscilloscope and gen-
erator
• Frequency range: 1kHz , 10kHz, 100kHz, 1MHz
• Frequency start: 10Hz, 100Hz, 1kHz, 10kHz
General information General information General information General information
• markers for amplitude/voltage and fre-
quency/time
• input coupling: DC, AC and GND
• 8 bit resolution
• storage of display and data
• supply from USB port (500mA)****
• dimensions: 205 x 55 X 175 / 8,2 x 2,2 x 7"
Spectrum analyser:
Spectrum analyser: Spectrum analyser: Spectrum analyser:
• frequency range: 0 .. 120Hz to 12MHz
• linear or logarithmic timescale
• operating principle: FFT (Fast Fourier Trans-
form)
• FFT resolution: 2048 lines
• FFT input channel: CH1 or CH2
• zoom function
Transient recorder:
Transient recorder: Transient recorder: Transient recorder:
• timescale: 20ms/Div to 2000s/Div
• max record time: 9.4hour/screen
• automatic storage of data
• automatic recording for more than 1 year
• max. number of samples: 100/s
• min. number of samples: 1 sample/20s
* NOTE: it is NOT recommended to use an USB * NOTE: it is NOT recommended to use an USB * NOTE: it is NOT recommended to use an USB * NOTE: it is NOT recommended to use an USB ---- HUB device, this can cause the software to stop working. HUB device, this can cause the software to stop working. HUB device, this can cause the software to stop working. HUB device, this can cause the software to stop working.
SPECIFICATIONS ARE SUBJECT TO MODIFICATIONS - DLL available for own development - www.velleman.eu
