Soldering - Solderen - Soudage - Löten - Soldadura - Lödning - Juottami nen - Saldatura - Solda
1
3
max.
40W
Resistor - Weerstand - Résistance - Widerstand -
Resistencia - Motstand - Vastus - Resistenze
2
START
1
M
K
185_r
ev
.1
◊
R1 : 100
(Brown, Black, Brown) - (Bruin, zwart, Brown) -
(Brun, noir, Brun) - (Braun, Schwarz, Braun) -
(Brun, Svart, Brun) - (Ruskea, Musta, Ruskea) -
(Marrón, Negro, Marrón) - (Castanho, Preto,
Castanho) - (Marrone, Nero, Marrone)
R...
DIODE
Watch the polarity !
Attention à la polarité !
◊
D1 : BAT85
3
2
IC socket
WATCH THE POSITION OF
THE NOTCH !
ATTENTION A LA
POSITION DE L’ENCOCHE !
!
◊
IC1 : 8p
◊
SW1 : Night / always
◊
SW2 : Glow worm / cricket
Switch
4
Diodes & LED assembly
6
1N5407
6x
A
B
LED
C
1N4007
◊
BUZ1
2x
2x
D
Piezo
7
solderside
Batteryholder
9
Watch the polarity !
Attention à la polarité !
◊
LD1
1N4007
Solar cell
10
◊
IC1 : VMk185
(programmed PIC10F200-I/PG)
IC
5
WATCH THE POSITION OF
THE NOTCH !
ATTENTION A LA
POSITION DE L’ENCOCHE !
A
B
◊
Zip fix (loops + hooks)
1
2
3
Zip fix
8
2cm 2cm
2cm 2cm
RED
BLACK
-
+
-
+
1
3
2
