Velleman К8061 User Manual
Page 8
8
Construction
IC1 : 6N136
IC2 : 6N136
IC3 : VK8061USB
(programmed PIC18F2550-I/SP)
IC4 : ULN2803
IC5 : ULN2803
IC6 : VK8061CPU
(programmed PIC16F871-I/P)
IC7 : TLC5628CN
IC8 : TLV274IN
IC9 : TLV274IN
IC10 : TLV274IN
IC11 : TLV274IN
21. IC's. Watch the position of the notch!
Mount the rubber feet on the solder side of the
PCB, see fig 1.0.
22. Rubber feet
FIG 1.0
23. Connection points
8
12
7
10
9
2
1
11
3
4
5
6
13
14
16
15
18
17
19
20
