Velleman VM106 User Manual
Page 19
19
Anschluss
VCR ... DVDR
DVD ... V
CR
S-video
Composite video
Output
Input
9V DC / 100mA
-
+
POWER
VM106
VIDEO SIGNAL CLEANER
VIDEO
* See manual for safety and operating instructions. - Developed in Europe
R
M O D U L E S
Videosignals Anzeige.
Netzanzeige
Netzconnector
S-video Eingang
Composite Eingang
Composite Ausgang
S-video Ausgang
Beim Anschluss des Adapters leuchtet die Spannungsanzeige wenn die Stromversorgung richtig ist. Die
Videosignalanzeige leuchtet wenn das Quellensignal vor Kopieren geschützt ist, und leuchtet solange das Videosignal
vorhanden ist.
