Connection diagram - Aansluitschema - Schéma de connexion -

Anschlussplan - diagrama de conexión

R G B

COM

+

-

-

+

12

/ 24VDC PO

W

ER

S

U

P

P

LY

Modifications and typographical errors reserved - © Velleman nv. Legen Heirweg 33, 9890 Gavere (Belgium) HVM192IR - 2013 - ED1

RGB LED STRIP

RGB LEDSTRIP

FLEXIBLE LED RVB

RGB LED-LEISTE

CInTa DE LED RGB

voedingsspanning 12-24VDC

tension d’alimentation 12-24 VCC

Spannungsversorgung 12-24VDC

tensión de alimentación 12/24VDC

3 x 2.5a MaX !

SInGLE COLOUR

EEnKLEURIGE LEDSTRIP

FLEXIBLE LED UnICOLORE

EInFaRBIGE LED-LEISTE

CInTa DE LED DE 1 COLOR

LED STRIP 1 x 8a max.

IR DEMODULaTOR

DEMODULaTEUR IR

IR-DEMODULaTOR

DEMODULaDOR IR

�����������������������

���������������������
