Velleman VM121 User Manual
Page 4

4
keyboard layout
KEYBOARD LAYOUT
1
3
5
7
2
4
6
8
SHIFT
Insert the batteries in the battery compart-
ment as indicated in the figure and close
the compartment.
Remark : Respect your national
and local laws when disposing of
empty batteries.
Output
channel
Output channel
with 'SHIFT'
Compatible with our
tuners/preamps & kits
1 9
Mute
2 10
Power
3 11
Volume
up
4 12
Preset
up
5 13 Volume
down
6 14
Preset
down
7 15
Source
8
All clear
Tuner seek
