4
Specifications & features
SPECIFICATIONS & FEATURES
This board can program a wide range of Microchip ® PIC™ microcontrollers
Features:
onboard configurable 40 pin. ZIF socket
easy to use programming PICprog2006™ software included
on board "In Circuit Serial Programming" connector
Specifications:
power supply: 15V DC, min. 300mA adapter (Ex. PS1508)
serial port connector: 9 p. SUBD
dimensions: 132x65x20mm / 5,23 x 2,57 x 0,79"
minimum system requirements:
IBM Compatible PC, Pentium or better
Windows™98/ME/ NT/2000/XP/VISTA
CDROM drive
free serial RS232 port required (*)
(*) not compatible with USB to serial (RS232) converter!
The Microchip name and logo, PIC, and PICmicro are registered trademarks of Microchip Technology Inc. in the USA
and other countries
Windows™ is a registered trademarks of Microsoft Corporation
4
Specifications & features
SPECIFICATIONS & FEATURES
This board can program a wide range of Microchip ® PIC™ microcontrollers
Features:
onboard configurable 40 pin. ZIF socket
easy to use programming PICprog2006™ software included
on board "In Circuit Serial Programming" connector
Specifications:
power supply: 15V DC, min. 300mA adapter (Ex. PS1508)
serial port connector: 9 p. SUBD
dimensions: 132x65x20mm / 5,23 x 2,57 x 0,79"
minimum system requirements:
IBM Compatible PC, Pentium or better
Windows™98/ME/ NT/2000/XP/VISTA
CDROM drive
free serial RS232 port required (*)
(*) not compatible with USB to serial (RS232) converter!
The Microchip name and logo, PIC, and PICmicro are registered trademarks of Microchip Technology Inc. in the USA
and other countries
Windows™ is a registered trademarks of Microsoft Corporation
