2
This dimmer is a plug-in module for our K8006 home modular light system suitable for incandescent lamps,
and halogen lighting. This dimmer uses phase control technology. The main advantages of this technology
are a reduced harmonic distortion on the mains and the fact that this dimmer can be used for electronic
transformer, used in low voltage halogen lighting.
Specifications:
 PLUG-IN’ module for use with our home modular light system K8006 only.
 Suitable for incandescent lamps, mains voltage halogen lighting and low voltage halogen lighting in
combination with an electronic transformer.
 Inductor- and filter free, reverse phase control technology with coolMOS™ FET-transistor.
 A brief push toggles on/off, while continued pushing engages dimming action
 “Soft-start” safety feature to make lamps last as long as possible.
 Non volatile memory for last set light intensity.
 Reduced harmonic distortion (less EMI), according to EN55015.
 LED status indication.
Features:
Operating voltages: 110-125V or 220-240V AC (50/60Hz)
Max. load: 300W/230V or 150W/115V, 0-98% adjustable.
dimming cycle speed: +/- 5 sec.
PCB dimensions: 65 x 57 x 20mm.
 It is not recommended to use this dimmer with wire-wound transformers.
Features & Specifications
