Processor
I/O
TI TMS320C642
4 Input/ 2 Output - 96 kHz/24-bit
Dynamic Range 100 dB per range (112 dB total)
Noise floor 22 dBA, 25 dBC, 30 dBz (for 40mV/Pascal)
THD + noise > 90 dB@ 1/4 dynamic range
Cross talk > 115 dB @ 1kHz
Random noise < 14 μV(A), < 17 μV(Z) @ 0.1 Hz
Anti-aliasing filter yes
Input filter (DC, AC) Adjustable: 0,1 to 16 Hz)
Low and High Pass Filters Low Pass: 0.5 Hz; High Pass: 20 kHz
Overload Detection Yes
Input/Output voltage 6 V pk-pk
Safe Max. input 25 Vpk-pk
Sensor Power Supply: ICP 4mA
Rugged Tablet from DAP Technologies - Model M9000
Operating system
Intel® Atom™ E660T 1.3 GHz, GB DDR2 SDRAM, USB Port
16GB high-speed solid state drive; up to 32 & 64GB
Windows® Embedded Standard 7
Display
7-inch WVGA (800 x 480), 550 nits
Sunlight viewable, Hardened touchscreen (Passive stylus or finger operation)
Light sensor for auto backlight adjustment
Connectivity Options WLAN, Bluetooth, WWAN (gobi 3000), GPS
Battery operation
1 Primary internal battery, 3000 mAh, 7.4V Lithium-Ion;
1 Secondary battery Li-ion battery pack, 7.4 V, 3000 mAh (hot-swappable)
Audio Speaker & 3.2 mm stereo headset jack
Operating temp -22 to +122 °F [-30 to +50 °C]; Charging T: 32 to +104 °F [0 to +40 °C]
Dimensions 230 x 185 x 60mm (9.00” x 7.28” x 2.36”)
Weight 1,4 kg (3.2 lbs)
Protection rating
Drop: Multiple 6ft (1.8m) drops on concrete
Sealing: IP67 (Rain, Humidity, 1 meter immersion)
ESD: 15 kV air discharge, 8 kV direct discharge
Humidity: 95% non-condensing
Temperature: MIL-STD-810-F
Vibration: MIL-STD 810E 514.5
Approvals FCC Class B, IC, RoHS,CE, WEEE
Warranty
Manufacturer’s warranty: 1-year limited warranty, parts & labor
Optional 3-year warranty extension
Options
Universal Imager with 5MP camera with auto-focus, OCR and video capture;
Signal Processing: Ensure by Signal-Ranger-MK3 DSP board
