Notes
Post processing interface
Compute the global level history
Display measurements with a time base
Display data stored (Lmin,Lmax,Leq)
Export data in a file
Data processing interface
Display every measurement recorded
Display start time and duration of each measurement
Display statistic (Leq,Lmin,Lmax,L%)
Export data in a XLS file
Conform to IEC 651/804 & ANSI S1.4 type 2 for dBA
Measurement types LEQ, SPL, SEL, LMAX, LMIN
Measurement range 31 to 105 dB
Frequency range 63 Hz to 8000 Hz
Frequency weighting A and C
Response time FAST and SLOW
Linearity range 75 dB
Display resolution 0.1 dB
Accuracy ±1.5 dB (94 dB @ 1 kHz)
Microphone MEMS (Micro-Electrical Mechanical System)
Numeric display 4-digit LCD
Display update rate 8 times per second
Bar graph display 3 dB per step (24 segments)
Bar graph update rate 8 times per second
Display warnings (OVER/UNDER range, MEMORY FULL)
Power supply 1 Lithium CR2450
Battery life 300 hours (approx.)
Operating conditions 32 to 140 ºF (0 to 60 ºC); 90 % relative humidity
Storage conditions -4 to 158 ºF (-20 to 70 ºC); 75 % relative humidity
Dimensions 5 3/16" X 2 5/16" X 5/8" (132 mm X 59 mm X 15 mm)
Specifications
The Piccolo is provided with windscreen, USB cable, windows
software, battery and plastic case.
Piccolo Sound Level Meter
Integrating SLM & Datalogger
For more info and free download : www.softdb.com/Piccolo_SLM.html
