3V Lithium Batteries
Engineering Specifications for RENATA 3V Lithium
Button Cells (MnO
2
/Li)
Maximum dimensions
(mm)
RENATA
Part name
RENATA
Part no
Nominal
capacity
(1)
(mAh)
Standard
discharge
current (1)
(mA)
Maximum
continuous
discharge
current (2)
(mA)
Weight
(g)
A
B
C
D
CR1025
700263
30
0.05
0.4
0.6
10.0
2.5
8.0
0.5
CR1216 MFR
100551
30
0.1
1.0
0.7
12.5
1.6
10.2
0.05 min
CR1220 MFR
100552
40
0.1
1.0
0.8
12.5
2.0
10.3
0.1 min
CR1225
700281
48
0.1
1.0
0.9
12.5
2.5
10.0
0.3
CR1616
700287
50
0.1
1.0
1.1
16.0
1.6
13.1
0.1
CR1620
700291
68
0.1
1.0
1.2
16.0
2.0
13.1
0.3
CR1632
700296
125
0.2
1.5
1.8
16.0
3.2
13.1
0.6
CR2016 MFR
100270
90
0.2
3.0
1.7
20.0
1.6
18.0
0.05 min
CR2025 MFR
100271
165
0.3
3.0
2.5
20.0
2.5
17.0
0.05 min
CR2032 MFR
100272
225
0.4
3.0
2.8
20.0
3.2
17.0
0.05 min
CR2320
700344
150
0.2
3.0
2.7
23.0
2.0
19.1
0.4
CR2325
700348
190
0.3
3.0
3.0
23.0
2.5
20.5
0.4
CR2430 MFR
100350
300
0.5
3.0
4.3
24.5
3.0
20.0
0.08 min
CR2430
700359
285
0.5
4.0
4.1
24.5 3.0
22.0 0.4
CR2450N
700377
540
0.8
3.0
5.9
24.5
5.0
22.2
2.5
CR2477N
700391
950
1.0
2.5
8.2
24.5
7.7
22.2
5.0
(1)
Nominal capacity values shown above are based on the respective standard discharge current and a cut-off voltage of 2.0V, at 23°C.
(2)
The maximum current is determined for a yield of 70% of the nominal capacity with a cut-off voltage of 2.0V, at 23°C. For the currents
exceeding those given above or pulsed current, please contact RENATA SA.
RENATA batteries are UL-approved (File No. MH14002).
Rev. 12 / 2010
