Ohaus RANGER COUNT 3000 COMPACT COUNTING SCALES Manual - Manual (Page 26)

EN-24
Ranger™ Count 3000
Series
Lock Print
[l.print]
Set the status.
OFF = Print menu is not locked
ON = Print menu is locked
Lock COM
[l.COmM]
Set the status.
OFF = COM menu is not locked
ON = COM menu is locked
End Lock
[End]
Advance to the next menu or return to the top of the current menu.
4.9 End Menu
Press ‘ No’ to advance to the Calibration menu. Press ‘Yes’ to exit the menu and return to the
current application mode.
4.10 Additional Features
To use the weigh below feature, remove AC power from the scale and remove the protective
cover for the weigh below opening. Install a suitable hook into the access hole at the bottom of
the scale as shown. Refer to section 6.4 for optional hook. Do not over tighten, tighten finger
tight. Mount the scale onto an appropriate assembly that allows free working space below the
hook. See figure 4-1.
Note:
Never allow the scale to rest directly on the hook.
Figure 4-1. Setup for the Weigh Below Hook
Weigh Below Hook
Access
