USB Interface

EN-3

BALANCE SETUP

A) The Ohaus Interface is preset to communicate using the following settings: 2400 baud, 7 bit,

no parity, no handshake. If different settings are desired, it will be necessary to change either
the balance settings, or the computer settings.

B) Upon installation of the interface, the balance will recognize the USB Interface and add

relevant items to the menu. Configure the balance to the desired USB and printing
parameters; refer to the balance User Manual for assistance in using the menus.

PRINT

Stable

On, Off

A-Print

Cont, On.Stbl, On.Acc*, 5sec, 15sec,
30sec, 60sec, off

End

Yes, No

*Note: Print and USB menu
selections may vary between
the different balance series.

USB

USB

On / off

Baud

600, 1200, 2400, 4800, 9600, 19200

Parity

7-even, 7-odd, 7-none, 8-none

Handshake

None, Xon-Xoff, RTS-CTS

END

Yes, No

SETUP DEFINITIONS

PRINT / Stable - On

Balance transmits stable data only.

PRINT / Auto Print – Continuous

Balance repeatedly sends data as fast as possible.

PRINT / Auto Print – On Stable

Balance automatically outputs data upon stability.

PRINT / Auto Print – (xx) sec

Balance sends data every (xx) seconds.

PRINT / Auto Print – Off

Only sends data when PRINT is pressed.

USB / USB –Off

Turns Interface off, saving battery power.

USB / Baud, Parity, Handshake

Set parameters to match printer or computer.

OPERATION

USB OUTPUT

With the Adapter installed the balance will operate in one of the following three ways:

USB = on, Auto Print = off, Stable = on or off
Pressing PRINT will send the display data based on the settings in the Menu.
If Stable is set to On, the balance will wait for a stable reading before sending data.

USB = on, Auto Print = on, Stable = on or off
The balance will automatically send data.
If Stable is set to On, only stable values will be sent.

USB = off
The interface is turned off. During battery operation, this saves significant power.
