EN-6 VX Series Floor Scale
TECHNICAL DATA
4.3. Specifications
TABLE 3. FLOOR SCALE SPECIFICATIONS
Platform Models VX2500L VX5000L VX10000L VX5000X VX10000X
Platform Dimensions
(W x D x H) 4’ x 4’ x 4.5” /
1,219 x 1,219 x 114 mm
5’ x 5’ x 4.5” /
1,524 x 1,524 x 114 mm
Capacity x
e
min
2,500 lb x 0.5 lb /
1,000 kg x 0.2 kg
5,000 lb x 1 lb /
2,200 kg x 0.5 kg
10,000 lb x 2 lb /
4,500 kg x 1 kg
5,000 lb x 1 lb /
2,200 kg x 0.5 kg
10,000 lb x 2 lb /
4,500 kg x 1 kg
Resolution NTEP 5000d NTEP 5000d NTEP 5000d NTEP 5000d NTEP 5000d
Material Epoxy painted carbon steel, treaded surface, fixed top plate, thickness 3/16” (up to 5000lb), 1/4” (10,000lb)
Load Cell 4 x Shear Beam, IP67, Nickel plated alloy steel, NTEP C3
Load Cell Output Impedance 350 Ω ± 3 Ω
Load Cell Excitation Voltage 5V ~15V DC/AC
Junction Box Side panel access, IP65 plastic case, 25’ (7.6m) cable length
Feet 4 x Ball-in-cup design, adjustable height
Operating Temperature 50°F to 104°F / 10 °C to 40 °C
Net Weight 220 lb / 100 kg 320 lb / 145 kg 335 lb / 152 kg 485 lb / 220 kg
Shipping Weight 285 lb / 129 kg 383 lb / 174 kg 395 lb / 179 kg 545 lb / 247 kg
Shipping Dimensions
(W x D x H) 5’ x 4’ x 1’ /
1,524 x 1,219 x 305mm
6’ x 5’ x 1’ /
1,524 x 1,829 x 305mm
4.4. Accessories
TABLE 4. LIST OF ACCESSORIES
Item Part Number
Ramp, 4’, Painted Steel, for VX2500L / VX5000L 80252766
Ramp, 5’, Painted Steel, for VX5000X 80252767
Ramp, 4’, Painted Steel, for VX10000L 80252795
Ramp, 5’, Painted Steel, for VX10000X 80252796
Ball-in-cup Feet, Set of 4 80252833
