EN-6 Navigator
®
4. SETTINGS
The User Menu allows the customizing of balance settings.
Note: Additional Sub-Menus may be available if Interface Options are installed. See Interface User
Manual for the additional setting information.
4.1 Menu Navigation
User Menu:
Sub-Menus: .C.a.l. .S.e.t.u.p. .M.o.d.e. .U.n.i.t. .E.n.d.
Menu Items:
Span
Lin
End
A-off
Disply
Bright
IR.LEFT
IR.RGHT
End
Count
Percnt
Hold
Accum
Check
End
ct, g, kg, grn,
lb, oz, lb:oz,
ozt, N, dwt,
thk, tsg, ttw,
tola, tical
End
Press and hold Menu until [
mMeNU] (Menu) is displayed. When released the first sub-menu [.C.a.l.]
(Cal) will be shown.
Press Yes to enter the displayed sub-menu or press No to advance to the next.
Selecting a sub-menu will display the first menu item. Press Yes to view the menu item setting or
press No to move to the next menu item. When viewing the setting, press Yes to accept the setting, or
press No to change the setting. When [
End] is displayed, press Yes to return to the sub-menu
selections or No to return to the first item in the current menu.
4.2 Cal Sub-Menu
• Span [ SpaN] (yes, no) - Initiates a span calibration procedure (zero and span). A span
calibration is important when initially setting up the balance.
• Lin [ Lin] (yes, no) - Initiates a linearity calibration procedure (zero, mid-point and span).
4.3 Setup Sub-Menu
The backlit LCD and (red) LED displays will have different menu items or settings based on the
functionality.
• Auto Off [ A-Off] (on, off) - When Auto Off is set to “on” the balance will turn off automatically
after 5 minutes of inactivity. Auto off is used to save battery power.
• Display [ disply] (on, auto, dim (LED), off (LCD)) - This setting controls the LCD backlight or
the LED digits; constant on, automatic turn off after 5 seconds of balance inactivity, dimming of
the LED after 60 seconds of balance inactivity or LCD backlight always off.
• Bright [ Bright] (hi, mid, low) - This setting controls the brightness of the LED display. LCD
models will not see this menu item.
• IR Sensor Left [ Ir.LEFt] / Right [Ir.rght] (Off, Tare, Function, Print, Zero, Display) - These
settings determine the role of the IR Sensors. “Zero”, “Print”, “Function” or “Tare” allows the IR
sensor to act the same as the related button. “Display” activates the display if Display-Auto is
set. “O
• ff” disables the sensor.
