Navigator
®
EN-1
1. INTRODUCTION
This manual contains installation, operation and maintenance instructions for the Navigator
®
Series.
Please read the manual completely before using the balance.
1.1 Safety Precautions
Please follow these safety precautions:
• Verify that the AC Adapter input voltage matches the local AC power supply.
• Only use the balance in dry locations.
• Do not operate the balance in hostile environments.
• Do not drop loads on the platform.
• Service should be performed only by authorized personnel.
1.2. Controls
Standard (non-approved) models – shown with LED display.
Button Functions
Zero
Yes
Short Press (when on): Sets display to zero
(when off): Turns balance on
Long Press (when on): Turns the balance off
Short Press (in Menu): Selects/accepts displayed setting
Print
Units
No Short Press: See Interface Manual for operation description.
Long Press: Toggles through active units
Short Press (in Menu): Toggles through available settings
Function
Mode
Back Short Press: Selects function setting
Long Press: Selects active Mode
Short Press (in Menu): returns to previous settings
Tare
Menu
Exit Short Press: Enter / clear a Tare value
Long Press: Enters User Menu
Short Press (in Menu): Quickly exit User Menu
IR Sensor-Left
IR Sensor-Right IR Sensors can be programmed to act as “touchless” buttons. See the
User Menu section 4.3 for the available settings.
The IR Sensors can be activated by a hand or other object that is placed about 12mm (½ inch)
above the sensor locations. The sensor activation distance will vary based on the reflective nature
of the object. If unwanted activations occur due to unique situations the sensors can be turned off.
