EN-9 Catapult 1000 Series Scales
5.3 Service Information
If the troubleshooting section does not resolve or describe your problem, contact
your authorized Ohaus service agent. For service assistance or technical support in
the United States call toll-free 1-800-526-0659 between 8.00 AM and 5:00 PM
EST. An Ohaus product service specialist will be available to provide assistance.
Outside the USA, please visit our web site,
www.ohaus.com to locate the Ohaus
office nearest you.
6. TECHNICAL DATA
The technical data is valid under the following ambient conditions:
Ambient temperature:
5°C to 40°C / 41° to 104° F
Relative humidity: 10% to 80% relative humidity, non-condensing
6.1 Specifications
TABLE 6-1. SPECIFICATIONS.
Model C11P9 C11P20 C11P75
Capacity x Readability
9 kg x 0.005 kg
20 lb x 0.01 lb
20 kg x 0.01 kg
44 lb x 0.02 lb
75 kg x 0.05 kg
165 lb x 0.1 lb
Weighing Units kg, lb
Modes Simple Weighing, Dynamic Weighing
Keypad 2-button mechanical keys
Calibration Weights 9 kg / 20 lb 20 kg / 40 lb 50 kg / 100 lb
Display 4-digit 7-segment, 20mm / 0.8 in characters
Display Indicators Stability, weighing unit, dynamic weighing, battery status
Tare range To capacity by subtraction
Stabilization Time ≤ 3 seconds
Maximum Overload 150%
Operating temperature/humidity
range 5° to 40°C / 41° to 104°F at 10% to 80% relative humidity,
non-condensing
Power Requirements
9-12 VDC 100mA AC Adapter (supplied)
3 “C” Alkaline or rechargeable batteries (LR14) optional
Auto Shut-Off 4 minutes no activity (battery operation only)
Typical Battery life 300 hours
Scale Dimensions (mm / in) 316 x 316 x 60/ 12.4 x 12.4 x 2.36
