Defender
TM
Scale Bases
80774416_E © Copyright Ohaus Corporation
OHAUS CORPORATION
* 7 Campus Drive
Suite 310
Parsippany, NJ 07054 USA
Tel: 800.672.7722
973.377.9000
Fax: 973.944.7177
www.ohaus.com
With offices throughout Europe,
Asia, and Latin America
* ISO 9001
Registered Quality Management System
Standard Features:
Defender Washdown Square, Square and Rectangular Bases
Defender Basic Washdown Rectangular and Rectangular Bases
Level Bubble Included
Durable Base Frame Construction
Stainless steel pans and stainless
or painted form-and-weld frames
(R, L sizes) provide maximum
durability, rigidity and structural integ-
rity. Load-unload
cycle tested
to ensure long-term
performance.
Removable Stainless Steel Pans
For quick cleaning, all bases come
with removable stainless steel pans
IP67 Loadcells
For added durability, all loadcells are protected to
IP67 against water and condensation
Fully Adjustable Feet
Four rugged, adjustable feet help
prevent slippage on wet or uneven
surfaces
Base Construction
Defender Square Washdown Bases feature
all stainless steel construction - pans,
basework and loadcells, for complete
washdown protection. Defender Square
and Rectangular Bases are made from
painted carbon steel with stainless steel
pans and aluminum loadcells.
Level Bubble Included
Fully Adjustable Feet
Four rugged, adjustable feet help
prevent slippage on wet or uneven
surfaces
IP67 Loadcells
For added durability, all loadcells are
protected to IP67 against water and
condensation
Removable Stainless Steel Pans
For quick cleaning, all bases come
with removable stainless steel pans
Base Construction
Defender Basic Washdown Bases also
feature all stainless steel construction.
Defender Basic Rectangular Bases are
made from painted carbon steel with
stainless steel pans and aluminum loadcells.
Durable Base Frame Construction
Defender Basic Rectangular Bases
are made from welded tubular steel,
providing economical durability for
industrial applications.
Load-unload cycle tested
to ensure long-term
performance.
Options and Accessories
Mounting Accessories
OHAUS Number
Base Mount Kit, T51P .................................................................................................80500722
Column Mount Kit, 13.75in/35cm, painted, T31P/T32XW ...........................80251743
Column Mount Kit, 26.75in/70cm, painted, T31P/T32XW ...........................80251744
Column Mount Kit, 13.75in/35cm, stainless steel, T31P/T32XW ...............80251745
Column Mount Kit, 26.75in/70cm, stainless steel, T31P/T32XW ...............80251746
Column Mount Kit, 13.75in/35cm, painted, T51P/T51XW ...........................80500723
Column Mount Kit, 26.75in/68cm, painted, T51P/T51XW ...........................80500724
Column Mount Kit, 13.75in/35cm, stainless steel, T51P/T51XW ...............80500725
Column Mount Kit, 26.75in/68cm, stainless steel, T51P/T51XW ...............80500726
Compatible with all existing columns for Champs with CD/CW11/CD31/33/CKW indicators
Compliance
• Legal for Trade: NTEP CC No. 01-048A1 for W and Q bases, 99-203A3 for H bases and 08-021 for B, V bases;
Measurement Canada Approval No. AM-5717 for W and Q bases, AM-5667 for H bases and AM-5632 for B and V
bases
• Safety and EMC:
c
UL
us
2005/95/EC low voltage directive: EN60950-1:2001, FCC Part 15 Class A 2004/108/EC
EMC directive: EN61326-1:1997; +A1:1998; +A2:2001; + A3>2003
• Other: Compliant to Directive 2002/96/EC on waste electrical and electronic equipment (WEEE)
• Quality: OHAUS quality management system registered to ISO 9001:2008
