Defender
TM
Bases
Painted and Stainless Steel Scale Bases
Defender Square Washdown Bench Scale Bases (W model)
Model
D10WR D25WR D50WL D100WL D250WX
Capacity x Readability
25 lb x 0.002 lb
10 kg x 1 g
50 lb x 0.005 lb
25 kg x 2 g
100 lb x 0.01 lb
50 kg x 5 g
250 lb x 0.02 lb
100 kg x 10 g
500 lb x 0.05 lb
250 kg x 20 g
Capacity x
Certified/Approved Readability
25 lb x 0.005 lb
10 kg x 0.002 kg
50 lb x 0.01 lb
25 kg x 0.005 kg
100 lb x 0.02 lb
50 kg x 0.01 kg
250 lb x 0.05 lb
100 kg 0.02 kg
500 lb x 0.10 lb
250 kg x 0.05 kg
Maximum Certified Resolution 1:5,000 1:5,000 1:5,000 1:5,000 1:5,000
Load Cell Cable 8.25 ft. / 2.5 m L x 6-wire
Load Cell Rated Output 2 mV/V ± 10%
Load Cell Excitation Voltage Maximum 20V (AC/DC) / Recommended 5~15V (AC/DC)
Load Cell Input / Output Resistance 387 ± 10 ohms / 350 ± 4 ohms
Leveling Components Externally visible level bubble and adjustable non-slip leveling feet
Operating Temperature 14°F to 104°F / -10°C to 40°C
Base Dimensions (A x B x C x D x E)
(refer to dimensional drawing)
12 x 12 x 3.7 x 2 x 13.2 in
305 x 305 x 95 x 52 x 335 mm
18 x 18 x 4.5 x 2.8 x 19.2 in
457 x 457 x 115 x 70 x 487 mm
24 x 24 x 5.4 x 3.5 x 25.2 in
610 x 610 x 137 x 90 x 640 mm
Shipping Dimensions (L x W x H)
19.3 x 16.1 x 17.3 in
490 x 410 x 440 mm
31.2 x 23.6 x 9.5 in
810 x 600 x 240 mm
39.4 x 29.9 x 9.8 in
1000 x 760 x 250 mm
Net Weight 26.9 lb / 12.2 kg 60 lb / 27.2 kg 77 lb / 35 kg
Shipping Weight 31.3 lb / 14.2 kg 64 lb / 29 kg 90 lb / 41 kg
NTEP CC No. 01-048A1 / Measurement Canada approval AM-5719
Defender Square Bench Scale Bases (Q model)
Model
D10QR D25QR D50QL D100QL D250QX
Capacity x Readability
25 lb x 0.002 lb
10 kg x 1 g
50 lb x 0.005 lb
25 kg x 2 g
100 lb x 0.01 lb
50 kg x 5 g
250 lb x 0.02 lb
100 kg x 10 g
500 lb x 0.05 lb
250 kg x 20 g
Capacity x
Certified/Approved Readability
25 lb x 0.005 lb
10 kg x 0.002 kg
50 lb x 0.01 lb
25 kg x 0.005 kg
100 lb x 0.02 lb
50 kg x 0.01 kg
250 lb x 0.05 lb
100 kg 0.02 kg
500 lb x 0.10 lb
250 kg x 0.05 kg
Maximum Certified Resolution 1:5,000 1:5,000 1:5,000 1:5,000 1:5,000
Load Cell Cable 8.25 ft. / 2.5 m L x 6-wire
Load Cell Rated Output 2 mV/V ± 10%
Load Cell Excitation Voltage Maximum 20V (AC/DC) / Recommended 5~15V (AC/DC)
Load Cell Input / Output Resistance 410 ± 10 ohms / 350 ± 4 ohms
Leveling Components Externally visible level bubble and adjustable non-slip leveling feet
Operating Temperature 14°F to 104°F / -10°C to 40°C
Base Dimensions (A x B x C x D x E)
(refer to dimensional drawing)
12 x 12 x 3.7 x 2 x 13.2 in
305 x 305 x 95 x 52 x 335 mm
18 x 18 x 4.5 x 2.8 x 19.2 in
457 x 457 x 115 x 70 x 487 mm
24 x 24 x 5.4 x 3.5 x 25.2 in
610 x 610 x 137 x 90 x 640 mm
Shipping Dimensions
19.3 x 16.1 x 17.3 in
490 x 410 x 440 mm
31.2 x 23.6 x 9.5 in
810 x 600 x 240 mm
39.4 x 29.9 x 9.8 in
1000 x 760 x 250 mm
Net Weight 26.9 lb / 12.2 kg 60 lb / 27.2 kg 77 lb / 35 kg
Shipping Weight 31.3 lb / 14.2 kg 64 lb / 29 kg 90 lb / 41 kg
NTEP CC No. 01-048A1 / Measurement Canada approval AM-5719
Defender Rectangular Bench Scale Bases (H model)
Model D15HR D30HR D60HR D60HL D100HL D150HX D300HX
Capacity x Readability
30lb x 0.005lb
15kg x 2g
60lb x 0.01lb
30kg x 5g
150lb x
0.02lb
60kg x 10g
150lb x 0.02lb
60kg x 10g
250lb x 0.05lb
100kg x 20g
300lb x 0.05lb
150kg x 20g
600lb x 0.1lb
300kg x 50g
Capacity x
Certified/Approved Readability
30lb × 0.01lb
15kg × 0.005kg
60lb × 0.02lb
30kg ×
0.01kg
150lb ×
0.05lb
60 × 0.02 kg
150lb × 0.05lb
60kg × 0.02kg
250lb × 0.1lb
100kg × 0.05kg
300lb × 0.1lb
150kg ×
0.05kg
600lb × 0.2lb
300kg × 0.1kg
Maximum Certified Resolution 1:3,000 1:3,000 1:3,000 1:3,000 1:2,500 1:3,000 1:3,000
Load Cell Cable 6.6 ft / 2 m L x 6-wire
Load Cell Rated Output 2 mV/V ± 10%
Load Cell Excitation Voltage Maximum 20V (AC/DC) / Recommended 5~15V (AC/DC)
Load Cell Input / Output Resistance 410 ± 10 ohms / 350 ± 4 ohms
Leveling Components Externally visible level bubble and adjustable non-slip leveling feet
Operating Temperature 14°F to 104°F / -10°C to 40°C
Base Dimensions (A x B x C x D x E)
(refer to dimensional drawing)
14 x 12 x 3.7 x 2 x 15 in
355 x 305 x 95 x 50 x 380 mm
19.7 x 15.7 x 4.1 x 2.4 x 20.9 in
500 x 400 x 105 x 60 x 530 mm
21.7 x 16.5 x 4.9 x 2.8 x 22.8 in
550 x 420 x 125 x 70 x 580 mm
Shipping Dimensions (L x W x H)
19.3 x 16.1 x 17.3 in
490 x 410 x 440 mm
29.1 x 27.2 x 9.1 in
740 x 690 x 230 mm
29.5 x 28 x 9.1 in
750 x 710 x 230 mm
Net Weight 20 lb / 9 kg 42 lb / 19 kg 54 lb / 24.5 kg
Shipping Weight 24 lb / 11 kg 48.5 lb / 22 kg 59.5 lb / 27 kg
NTEP CC No. 99-203A3 / Measurement Canada approval AM-5675
Features:
• Square Pan
• All 304 Stainless Steel
Design
• Weld/Fold Steel Plate
Base (R, L sizes)
• Stainless Steel IP67
Loadcell
• 150% Safe Overload
Capacity
• 10,000-12,500d
• 5,000d NTEP
Certified/
Measurement
Canada Approved
Features:
• Square 304 Stainless
Steel Pan
• Painted Carbon Steel
Frame
• Weld/Fold Steel Plate
Base (R, L sizes)
• Aluminum IP67
Loadcell
• 150% Safe Overload
Capacity
• 10,000-12,500d
• 5,000d NTEP
Certified/
Measurement
Canada Approved
Features:
• Rectangular 304
Stainless Steel Pan
• Painted Carbon Steel
Frame
• Weld/Fold Steel Plate
Base (R, L sizes)
• Aluminum IP67
Loadcell
• 150% Safe Overload
Capacity
• 6,000-7,500d
• 2,500d - 3,000d
NTEP Certified /
Measurement
Canada Approved
