VX Series
Standard Floor Scales and Platforms
Compliance
• Safety and EMC: EN60950, EN61326, FCC, CE,
c
UL
us
• Legal for Trade (Made from Certified weighing components): NTEP: T32XW Indicator: CC 08-066A1 /
VX Platform: CC 08-069 / Load cells: CC 91-043A4
• Quality: OHAUS quality management system registered to ISO 9001:2008
Specifications
Platform Models VX2500L VX5000L VX10000L VX5000X VX10000X
Dimensions 4’ x 4’ x 4.5” / 1,219 x 1,219 x 115 mm 5’ x 5’ x 4.5” / 1,524 x 1,524 x 115 mm
Material Painted Carbon Steel, treaded surface, fixed top plate, thickness 3/16” (up to 5000lb), 1/4” (10,000lb)
Capacity x Readability
2,500 lb x 0.5 lb /
1,000 kg x 0.2 kg
5,000 lb x 1 lb /
2,200 kg x 0.5 kg
10,000 lb x 2 lb /
4,500 kg x 1 kg
5,000 lb x 1 lb /
2,200 kg x 0.5 kg
10,000 lb x 2 lb /
4,500 kg x 1 kg
NTEP Resolution NTEP 5000d NTEP 5000d N/A N/A N/A
Maximum Central Load 100% of maximum capacity
Safe End Load Capacity 100% of maximum capacity
Load Cell 4 x Shear Beam, IP67, nickel plated alloy steel
LC Output Impedance /
Excitation Voltage
350 Ω ± 3 Ω / 10V recommended~15V max, AC/DC
Junction Box Side panel access, IP65 plastic case with 25’ indicator cable
Feet 4 x Ball-in-cup design, adjustable height
Operating Temperature 50°F to 104°F / 10 °C to 40 °C
Net Weight 220 lb / 100 kg 320 lb / 145 kg 340 lb / 154 kg 500 lb / 227 kg
Shipping Weight 300 lb / 136 kg 400 lb / 181 kg 420 lb / 191 kg 590 lb / 268 kg
Scale Models VX32XW2500L VX32XW5000L VX32XW10000L VX32XW5000X VX32XW10000X
Indicator Model T32XW
Indicator Construction 304 stainless steel, NEMA4X/IP65 dust and water protection
Weighing Units lb, kg, oz, g, lb-oz
Modes Weighing, Counting* (min APW 1d)
Display 1 in / 25 mm high, 6-digit, 7-segment, bright white backlit LCD
Keypad 4-button, raised with tactile positive feedback membrane switches
Stabilization Time Within 2 seconds
Auto-zero Tracking Off, 0.5, 1 or 3d
Zeroing Range 0%, 2% or 100% of capacity
Span Calibration 5 lb or kg to 100% of capacity
Interface RS232C, bi-directional
Power 100-240 VAC / 50-60 Hz, internal power supply
Battery Internal rechargeable sealed lead acid battery (58-hour operation on full charge)
Indicator Dimensions 8.3 x 2.8 x 5.8 in / 212 x 71 x 149 mm
Scale Shipping Dimensions (WxDxH) 60 x 48 x 14 in / 1,524 x 1,220 x 356 mm 72 x 60 x 14 in / 1,829 x 1,524 x 356 mm
Scale Shipping Weight 330 lb / 150 kg 430 lb / 195 kg 450 lb / 204 kg 615 lb / 279 kg
* Counting feature not NTEP certified
