OHAUS VX Series
Standard Floor Scales and Platforms
Performance, Ruggedness, Ohaus Quality & Value
The OHAUS VX Series is a portable low-profile floor platform and indicator scale package. It is the ideal
solution for freight consolidators, forwarders, processing plants, resellers, shipping and receiving depart-
ments, as well as startup businesses. Quick connects and factory calibration allows the package to operate
out-of-the-box with minimal setup. This time saving solution combines a 5000d NTEP approved floor scale
(VX2500L and VX5000L) with four analog sealed load cells, and a stainless steel NEMA 4X/IP65 indicator
(T32XW) featuring an RS232 interface, high-visibility backlit LCD display, counting function and easy-to-
operate positive feedback keys.
Standard Features Include:
•
2,500 lb, 5,000 lb, and 10,000 lb scale capacities
•
4’ x 4’ and 5’ x 5’ platforms with structural bracing that ensures a rigid construction
•
3/16” (up to 5,000lb models) and 1/4” (10,000lb models) thick top plate with raised cross-hatch surface
for added durability and slip resistance
•
Four IP67 nickel plated alloy steel load cells
•
Side access NEMA4X/IP65 dust and water protected junction box with 25’ long cable
•
Features eye bolt mounting holes to allow easier lifting and positioning of the platform
•
Factory-wired and pre-calibrated with OHAUS T32XW stainless steel indicator featuring:
-
304 stainless steel construction with NEMA 4X/IP65 protection
-
Backlit LCD display with high-visibility 1” high digits
-
Five weighing units (lb, kg, g, oz, lb:oz)
-
Piece counting mode for warehousing and inventory applications
-
Wall mount bracket included
-
Rechargeable lead acid battery operation
VX Series shown with optional ramp
VX Series Platform with
T32XW indicator
