5000 Series
Standard Indicators
Features
T51P: ABS plastic housing with internal rib reinforcements, reversible rear cover, backlit LCD weight display,
checkweighing indication (green, yellow, red), membrane keypad with raised tactile keys, built-in bi-directional
RS232 with manual/continuous/interval printing, external tare input, hardware configuration lockout switch,
internal switching power supply with line cord and battery power using 6 “C” cell batteries.
T51XW: Stainless steel water resistant NEMA 4X / IP66 housing, integral faceplate supports for easy servicing,
backlit LCD weight display, checkweighing indication (green, yellow, red), membrane keypad with raised tactile
keys, built-in bi-directional RS232 with manual/continuous/interval printing, external tare input, hardware configu-
ration lockout switch, internal switching power supply with hardwired cord.
Options and Accessories
Internal rechargeable NiMH battery pack, 2nd RS232 interface, RS485/422 interface, AC Relay or DC Relay,
column mount kits, scale front mount bracket, interface cables, printer.
Other Features
Zero point calibration, calibration test, span or linear calibration, selectable auto-zero tracking range, selectable
stability range, selectable averaging level, selectable LCD backlight, selectable auto shutoff, retain zero weight data
after power-off, Geo gravity adjustment, selectable key beep, key function lock, menu lock, selectable power-on
and calibration unit, battery status display, display of gross/net weight, indication of stability, center of zero, over-
and underweight, overload and underload conditions. Configuration menus for PRINT1, PRINT2, COM1, COM2,
and I/O.
Compliance
• Legal-for-Trade: NTEP (CC No. 08-039), Measurement Canada (Approval No. AM-5687)
• Safety and EMC:
c
UL
us
2005/95/EC low voltage directive: EN60950-1:2001, FCC Part 15 Class A 2004/108/EC
EMC directive: EN61326-1:1997; +A1:1998; +A2:2001; + A3>2003
• Other: Compliant to Directive 2002/96/EC on waste electrical and electronic equipment (WEEE)
• Quality: OHAUS quality management system registered to ISO 9001:2008
Specifications
Indicator Models T51P T51XW
Capacity Range 1 to 999,950 kg/lb
Maximum Displayed Weighing Resolution 1:30,000
Maximum Displayed Counting Resolution 1:300,000
Certified/Approved Resolution 1:10,000
Minimum Average Piece Weight (APW) 0.1d
Weighing Units kg, lb, g, oz, lb:oz, metric tonnes, custom unit
Modes Static Weighing, Dynamic Weighing, Counting, Checkweighing, Percent Weighing, Display Hold
Housing ABS plastic with internal reinforcing ribs 304 stainless steel enclosure
Display 6-digit, 7-segment LCD, 25mm/1 inch high digits, with high-contrast white LED backlight
Checkweigh Indication 3-color checkweigh LED with configurable beeper signal
Keypad 4 function membrane switches, raised tactile keys
Ingress Protection –– NEMA 4X / IP66
Load Cell Excitation Voltage 5V DC
Load Cell Drive Up to 8 x 350 ohm Load Cells
Load Cell Input Sensitivity Up to 3 mV/V
Stabilization Time Within 2 seconds
Auto-Zero Tracking Off, O.5, 1 or 3d
Zeroing Range 2% or 100% of capacity
Span Calibration 1 kg/lb to 100% of capacity
Interface
Built-in RS232 and External Tare Input included
Optional 2nd RS232, RS422/485, AC Relay or DC Relay available
Overall Dimensions (inc. bracket) (W x D x H) 10.2 x 2.7 x 8.8 in / 260 x 71 x 224 mm 10.3 x 3 x 8.7 in / 262 x 76 x 212 mm
Enclosure Dimensions (W x D x H) 10.2 x 2.7 x 6.6 in / 260 x 71 x 168 mm 10.3 x 3 x 5.8 in / 262 x 76 x 149 mm
Net Weight 3.3 lb / 1.5 kg 7.7 lb / 3.5 kg
Shipping Weight 5.0 lb / 2.3 kg 9.5 lb / 4.3 kg
Shipping Dimensions (W x D x H) 13 x 9.5 x 7 in / 330 x 240 x 180 mm
Operating Temperature Range 14°F to 104°F / -10°C to 40°C
Relative Humidity Range Maximum 80% up to 88°F/31°C, decreasing linearly to 50% at 104°F/40°C
Power
100-240 VAC / 50-60 Hz
Internal universal power supply, line cord
6 ‘C’ cell batteries (not supplied) with 80 hour life
Opt. Int. rechargeable NiMH battery (30-hr. typical operation)
100-240 VAC / 50-60 Hz
Internal universal power supply, hardwire cord
Opt. Int. rechargeable NiMH battery (30-hr. typical operation)
